U13
U13 for Commercial Applications and Agriculture UAV
Specifications:
KV.....................................................................................................85
Configu ration.....................................................................................18N24P
Motor Dimensions (Dia.*Len)...............................................................Φ118.4×56.8mm
Weight(g)...........................................................................................1280g
ldle current(10)@10v(A).......................................................................1.25A
No.of Cells(Lipo).................................................................................6-12S
Max Continuous current(A)180S..........................................................65A
Max Continuous Power(W)180S...........................................................3120W
internal resistance...............................................................................23mΩ
Specifications:
KV............................................................................................................100
Configu ration.............................................................................................18N24P
Motor Dimensions (Dia.*Len).......................................................................Φ118.4×56.8mm
Weight(g)..................................................................................................1300g
ldle current(10)@10v(A)..............................................................................1.64A
No.of Cells(Lipo).........................................................................................6-12S
Max Continuous current(A)180S..................................................................80A
Max Continuous Power(W)180S...................................................................3848W
internal resistance......................................................................................18mΩ
